Antistatic Safe Product

ANTISTATIC (ESD) APRONS
Test Warp Weft Unit Method
Yarn PFY 75D PFY 100D Denier
FCF 24 DTEX 24 DTEX BASF
Density 180 97 Threads / Inch
Weave 0.5 TWL (2.5 mm Grid)
Width 58"/60" 58"/60" Inch x YD



Weight 105 105 Gr / M2



Cover Factor 2498 2498 - _
Air Permeability 10.4 10.4 Cm2 / Cm2 / Sec JIS-L1096
Moisture Permeability 363.3 363.3 GR / m2 / HR JIS-L1099
Filtration Efficiency
0.3pm - 0.5pm
80 — 85 80 — 85 % LES RP-CC-003-87-T
MODIFIED
Tearing Strength 2240 2120 Gr



Tensile Strength

95.6 64.8 Kg



Friction Static Voltage Below 10 Below 10 Volts JIS-L1094B
Surface Resistivity 105 - 106 105 - 106 Q/Sq ASTM D 257
Static Decay
5,000V — 500V
0.01 0.01 Sec FTS M4046 S101C
Abrasion Resistance 61 61 Cycles JIS-L1096 Univ.



Laundry Recommendation :

Washing : Temp: 40°C, Ph — 7.0

Rinsing : DI Water : 10e 18w

Dry : 60°C Dry Chamber with Hanger Installed

Recommendable Washing Times : 5 50 Times

* Note: Do Not Squeeze By Hand / Do Not Iron

STATIC (ESD) WRIST BAND
Length 220mm
Inner Surface Elastic Nylon with silver plated threads
Outer Surface Elastic Nylon, insulative
Color Light Blue, Maroon
Resistance 150-200 Ohm/inch
Plastic Parts ABS/PC
Back Plate 304 Stainless Steel, Non-allergenic



Coil Cord

Conductor 7-Strand Twin tinsel wire
Jacket Insulation 90 Shore A Polyurethane
Wire Diameter 0.10"
Coil Diameter 0.04'± 0.02'
Molding Material Polyurethane
Color Light Blue, Black
ESD Shoes
ESD Shoes

DESCRIPTION :

Material Type PVC
Available Sizes (MM) 230, 240, 250, 260, 270, 280, 290, 300
Weight
800 +/- 100 grms/Pair
Surface Resistivity (Bottom sole) 106 - 109 Ohms/Sq
Resistivity (RTG) 105 – 108 Ohms
Color Upper cover – White
Bottom Sole – Grey
Material Upper cover – Wet PU 1.5 mm + Non-woven 0.9mm (T) + ESD Tricot
Tapping - Wet PVC 0.4 mm (T) + 15 mm (W)
Inner Sole - Polyester + Black Conductive Thread.
Bottom Sole - PVC Injection with ESD Compound.
Thread - All round for better enforce
Application ESD Control heavy duty controlled area.
ANTI - STATIC (ESD) HEEL STRAP
ANTI - STATIC (ESD) HEEL STRAP

Constructed of non-piece non-marking material, with Velcro adjustment through a D-ring buckle and a gray conductive non-marking tab.Provides a mean to dissipate chanrges from Mobile personnel working in an area with conductive flooring.Fit most shoes and bots sizes.
The heel/toe grounder is made out of a special 2 layer non-marking rubber material. The inner layer in contact with shoes / boots, comes in either static dissipative material. The outer layer, in contact with the floor, comes in black conductive material. The unit has a molded I-mega oh current limiting resistor on the tab.
The heel/toe grounder is made out of special single-layer black conductive non-marking rubber material. the unit has a I-mega ohm current resistor on the tab.

ANTI - STATIC (ESD) HAND GLOVES
ANTI - STATIC (ESD) HAND GLOVES
Features Applications
Have excellent ESD protective Properties Electronics assembly
Are elastic, absorbent and anti-slopping
Computer assembly
Gloves is embossed with PVC Small parts handling
Mainly made of polyster fibers knitted with a conductive carbon line every 10mm apart Assembly, maintenance, Packaging
Electrical Properties
Surface Resistance 107 ohm ANSI/ESDSTM 11.11-2006
Physical Properties
Size X-Small Small Medium Large
Length 20.5mm 21mm 21.8mm 33mm
Width 8.2cm 8.5cm 9cm 9.5
Cuff Color Light Green Yellow Red White
Standard Packing
Inner Packing 100 pcs/bag
Outer Packing 10 bags/carton (1000 pcs per carton)
ANTI - STATIC (ESD) BRUSH
Sr No. Model No. Picture
1 SM 01 Tooth Type Small
2 Sm 02 Tooth Type Medium
3 SM 03 Tooth Type Large
4 SM 04 Paint Type Small
5 SM 05 Paint Type Medium
6 SM 06 Paint Type large
7 SM 07 Pen Type Small
8 SM 08 With Handle
ANTI - FATIGUE MAT
ANTI - FATIGUE MAT

Static dissipative anti-fatigue mat is widely used on the floor for operator standing long hour in production line. Ideal for lining metal shelving, rolling carts and floor, provide a non-skid, nonabrasive, cushioning effect and protection from physical shock

The material is suitable for used in cleanroom environment..

  • • Homogenous material
  • • Material is static dissipative
  • • Good cushioning effect.
  • • Surface resistance : < 9.0 E9 Ohm
  • • Colour : Black
  • • Size : 600 x 900 x 16 mm
  • • Suitable for ESD Cleanroom, Mechanical Industries, Automation Industries ect..



Basic Properties Properties Units Specification
Material - Polyurethane
Colour - Black
Weight KG 2.5
Length CM 90 +/- 1%
Width CM 60 +/- 1%
Thickness MM 15
Mechanical Intensity Sh-A 30 ~ 40
Density Kg/cubic meter 380 +/- 10 %
Compressibility % 50
Degree of Abrasion Cubic mm 180
Tensile Strength Mpa 2
Elongation % 500
Crushing Strength N/mm 4
Stability (Anti-slip) R/V 10/11
Electrical Resistance Surface Ohm 1 x 10E8 ~ 5 x 10E9
Heat The Lowest Point for use ° C 80
Available highest point ° C 120
ANTI - STATIC (ESD) COMPONENT ORGANISER
ANTI - STATIC (ESD) COMPONENT ORGANISER

SPECIFICATIONS :

  • • Cabinet Size : 400mm x 250mm x 160mm
  • • Size of drawers : 150mm x 75mm x35mm.
  • • Art No. : ACO 25 with 25 Drawers
ANTI - STATIC (ESD) FUME ABSORBER
ANTI - STATIC (ESD) FUME ABSORBER

Smoke Absorber

Soldering materials is made by, lead and many kinds of chemical active solvent, when soldering, toxic ingredients come out, which made many people getting headache, faint and so on. Use 493 smoke Absorber can remove toxin gas quickly and efficiency to proof health of workers.



FEATURES :

  • • Compact structure, easy to move.
  • • White, black, gray color. Black one can eliminate electrostatic
  • • Activate carbon filter is replaceable.
  • • Adopted double roll axis, rotate stable, low noise.



SPECIFICATIONS :

Power supply AC220V 50HZ/AC110V 60HZ
power consumption 30W
Dimension (W)220×(H)270×(L)168mm
Weight 1.5kg
Accessories: Activate card filter 3Pcs/kit



Active Carbon Filter

Size 130×130×10mm
Active Carbon 12g
Absorb 4g

ESD Bubble Bag

ANTI - STATIC (ESD) PACKAGING BAGS

PRODUCT DETAILS:

Material LDPE ESD Bubble
Design Bag Type
Color Pink
Size 100 x 150 mm & More
Customized Yes



APPLICATION :

ESD Bubble Bag is that which is specifically designed for preventing static damage in packaging components such as electronic products and other products or static sensitive products. We manufacture anti-static packaging products in diverse shapes and forms and from various materials. We can also manufacture anti-static packaging as per the specifications of our customers.



FEATURES :

  • 60-micron bag
  • Bubble wrap inside
  • With pod jacket
  • Waterproof bags
  • Security bags



(ESD) TSS Bags

ANTI - STATIC (ESD) PACKAGING BAGS
ANTI - STATIC (ESD) PACKAGING BAGS
Surface Resistance 10^6 to 10^9 ohms
Sealing Type Zipper Top
Design Type Customized
Color Grey /Black
Size 150 x 200 mm & More
Material Dissipative Polyester Layer + metalized Layer+ Antistatic P.E. Layer



Application:

Static Shielding Bags is that which is specifically designed for preventing static damage in packaging components such as electronic products and other products or static sensitive products. We manufacture anti-static packaging products in diverse shapes and forms and from various materials. We can also manufacture anti-static packaging as per the specifications of our customers.



ANTI – STATIC PINK POLY BAG

ANTI – STATIC PINK POLY BAG
Material LDPE impregnated with A/S agent
Surface Resistance 10^3 to 10^11 ohms
Surface Handling Offset Printing
Thickness 0.05 mm
Design Type Customized
Color Pink
Size 100 x 150 mm & More

We are one of the eminent manufacturers of Anti-Static Pink Poly Bag.



Application:

Anti-Static Pink Poly Bag is that which is specifically designed for preventing static damage in packaging components such as electronic products and other products or static sensitive products. We manufacture anti-static packaging products in diverse shapes and forms and from various materials. We can also manufacture anti-static packaging as per the specifications of our customers.

ANTI - STATIC (ESD) SAFE CURTAIN

PRODUCT DETAILS :

Minimum Order Quantity 1 Roll
Material PVC material with permanent antistatic agent
Surface Resistance 10^3 to 10^9 ohms
Surface to Ground Resistance 10^9 ohms
Width 1.37 m
Thickness 0.3 mm, 0.5 mm

ESD Caution Tape


DESCRIPTION :

A self-adhesive warning tape for use in the indentification and separation of the static sensitive Areas.

This product can also be used for caution signs

Can be customise to other languages

Caution Tape
Caution Tape

Physical Properties
Vinly Base Material 4 nil
Polyster Coat 1 nil
Adhesive Base 1 nil
Release liner - -
Roll Size (Wide x Length) 76 x 1650 mm
Packaging 12 Rolls per case
Colour Yellow background with black print



ESD KAPTON TAPE


Kapton Tape (ESD)

TECHNICAL SPECIFICATION :

Color Mainly Tawny
Material Durable Polyimide and Silicone
Size 0.06 mm thickness x 12 mm (width) to 50Mtr (length)
Length About 33m /100ft.
Heat resistance About 280°C.
One-side self-adhesive
High insulation, high temperature resistance, acid and alkali-resistance, low electrolysis, mechanically sound, crocking resistance, tear-resistance, without rest on surface when tear
Ideal for protecting sensitive printed circuit board (PCB) components such as gold leads and gold fingers during the process of wave soldering.
Also extensive use as electrical insulation for transformer, motor, coil, capacitor and frequency conversion power supply in electronic industry.



Brown Conductive Grid Tape


FEATURES :

Easy tear and smooth dispensing with good finger tack and adhesion

APPLICATIONS :

Recommended for use in clean room and static safe work station

PHYSICAL PROPERTIES :

Property Method Unit Values
Tensile Strength / Longitudinal ASTM D 882 N / mm sq. 160
Tensile Strength / Transverse ASTM D 882 N / mm sq. 720
Elogation / Longitudinal ASTM D 882 % 160
Elogation / Transverse ASTM D 882 % 50
Base Film Thickness - Micron 30
Peeling Force - N 12
Static Decay Time @ 15% RH, 73 oF FTMS 101B Sec. 0.5
  Method 4046 (mil-8-817058 Decay Test)
Resistivity
Heavy Duty Copolymer Layer ASTM D257 Ohm/Sq 10 E3 - 10 E4
Conductive Grid ASTM D257 Ohm/Sq 10 E3 - 10 E4
Antistatic Adhesive Copolymer Layer ASTM D257 Ohm/Sq < 10 E 9



Floor Marking Tapes


WRIST STRAP TESTER Z102

PRODUCT DETAILS

Feature

Heat Resistant, Waterproof

Color

All types of Colour

Width

1 inch, 2 inch, 3 inch

Length

25 meter



FEATURES :

  • • Highly visible
  • • Hard wearing
  • • Adheres to carpet and solid floors



SPECIFICATIONS :

  • • Material: PVC Material



Anti Skid Tape


Anti Skid Tape

Make

Regular

Width

2 inch

Length

8 mtr

Color

Black Only

EDS Top Fit Gloves



MATERIAL CONSTRUCTION :

Materials 300 Denier (Carbon 60D, 6F / Nylon 240D, 96F)
Size S/6, M/7, L/8, XL/9
Properties Manufactured with pliable carbon thread seamless
Polyurethane breathable PU coating on each top Antitatic and Shielding
Packing Individual Packing
300prs/carton
Color of Cuff Small-white, Medium-Green, Large-Grey, XLarge-Yellow
Caution Do not use detergents containing bleaches
Avoid direct contact with electric current
Do not contact materials above 70o C
Surface Resistivity 10e8-10e9 ohm/sq



Length (±5mm) S M L XL
Length of glove (From top of Middle fingertip of cuff end) 175 185 195 215
Palm width (±5mm) 70 75 85 85
Cuff (±5mm) 50 50 60 60
Weight (in gram) (±2) 15 17 19 22



APPLICATIONS :

  • • Assembling LSI, VLSI, Semiconductors, computers and precise instruments
  • • To prevent from miscellaneous disturbances or accidents due to static electricity
Disposable CPE PVC Shoe Cover
Disposable CPE PVC Shoe Cover



Material and Size
Material LDPE + LLDPE
Size 15 x 36 cm (+/- 1 CM)
Weight 2.7 G/pc (+/-0.5G)
3.5 G/pc (+/-0.5G)
Colour Blue
Type Welded
Dimension and Weight
Inner Packing 10 pcs/roll ; 10 roll / polybag
Box Packing 20 bags/ctn
Carton Dimension 51 cm x 41 cm x 52 cm
Anti–Fatigue Mat
Size 21 inches
Material PP Non Woven

FEATURES :

  • • Complete hair covering made from soft comfortable, thermally bonded lightpolypropylene fibre with an encapsulated elastic edge.
  • • High air permeability
  • • Suitable for use in electronic manufacturing, restaurants, food processing, hospital.
  • • Sanitation and quality in accordance with CE, FDA, ISO 9001 Standards



Packaging

100 pcs/bag, 2000 pcs/ctn

FACES MASK - DISPOSABLE
Mask Securing Method Earloop
Application Surgical, Laboratory Use, Dental, Medical Procedure
Material Three Ply Non-Woven, Two Ply Non-Woven



We are among the pre-eminent organizations, involved in manufacturing, supplying, wholesaling, trading, exporting and importing Disposable Faces Mask.



FEATURES :

  • • High tearing strength
  • • Skin-friendly
  • • Comfortable to wear
  • • Free from contamination
  • • Bio-degradable
  • • Disposable
Finger Cot, Pink

APPLICATIONS :

  • • Protecting from skin, flakes, oils, chemical and solvent splash
  • • Class 100 cleanroom & ESD control room use
  • • Handling thin films, optics and precision assembly

PHYSICAL PROPERTIES :

Product Material 100% Pure Natural Rubber Latex
Size S, M, L , XL
Color Pink
Surface Textured tip
Resistance > 10 9 Ohm



Storage

Store in a cool, dry place. Do not expose to direct sunlight or fluorescent light.



Exposure Data

Contains natural rubber latex which may cause allergic reactions in some people. Please consult physician should this occur.

IPA DISPENSER BOTTLE

Product Details :

Bottle Material Plastic
Size 150 ML
Color Blue/Pink/white
Design Type Standard
Surface Resistance 10^6 to 10^9 ohms
Capacity 150 ML
Cap Material Stainless Steel



APPLICATION :

  • • Single touch pumps top bottle for solvents, cleaners and alcohol.
  • • Ideal for clean rooms and PCB soldering work.

FULLY AUTOMATIC SHOE COVER DISPENSER

AIR SHOWER
Electrically Operated 220 V AC 50 Hz / 110 V AC 60 Hz
Shoe/Sandal Type Sports , Formal, etc
Brand SK-CM-W
Size 63x31x75 cm (LxWxH)



APPLICATION :

  • • For use in hospital, factory, laboratory, home, clean room, sample room and other places where clean dust free environment is maintained

MANUAL SHOE COVER DISPENSER

MANUAL SHOE COVER DISPENSER
Size 49.5x25.5x17 cm
Shoe/Sandal Type Sports , Formal, etc
Brand SK-D
Uses Hospital, Factory, Laboratory, Home



APPLICATION :

  • • For use in hospital, factory, laboratory, home, clean room, sample room and other places where clean dust free environment is maintained

SEMI-AUTOMATIC SHOE COVER DISPENSER

SEMI-AUTOMATIC SHOE COVER DISPENSER
Size 61x23x92 cm
Shoe/Sandal Type Sports, Formal, etc
Brand SK-H
Usage Hospital, Factory, Laboratory, Home, Clean Room



APPLICATION :

  • • For use in hospital, factory, laboratory, home, clean room, sample room and other places where clean dust free environment is maintained.
Sticky MAT
Sticky MAT
Structure
First Cover Sheet 60
30 Disposable Sheets  50
Self Adhesive sheets  80
Last Cover Sheet 60
Numbering Mark Numbers (30 to 1) on the 30 peel tags of the mat
Pad Thickness 2 mm
Stickiness
Grade A 300 +/-20 g / 25 mm
Grade B 400 +/-50 g / 25 mm
Properties
Ability of Dust removal 99.9% in five step (weight 100kg)
Sizes Available 24" x 36", 26" X 45"
Colour Available Blue, Other colur on indent basis
Tensile Strength More than 1.2 kg/10mm
Heat Resistance Pass at 70 +/- 3 oC / 48 hr
Cold Resistance Pass at - 13 +/- 3 oC / 48 hr
Packaging
1 Carton, 10pads, 30 sheets per Pad

Designed by : MID | Hosted by : GID | Promoted by : PBD
